Causes of No Water Discharge in Horizontal Split Case Pumps

During operation or commissioning, one of the most common issues encountered with a horizontal split case pump is the failure to discharge water or insufficient water output. If not promptly diagnosed and resolved, this issue can not only affect system performance but may also cause damage to the pump body and motor. This article analyzes the common causes of this problem from structural, installation, and operational perspectives, and provides targeted troubleshooting recommendations.

I. Common Causes for No Water Discharge in Horizontal Split Case Pumps

1. Air Leakage or Poor Sealing in the Suction Line

Air entering the suction system is one of the primary reasons why a horizontal split case pump fails to discharge water. If air leaks occur at suction line connections, flange gaskets, stuffing boxes, or vacuum gauge joints, air pockets will form inside the pump, preventing it from creating the necessary vacuum and thus stopping suction.

Solutions:

Check the sealing condition of suction piping and joints using soapy water or a vacuum gauge to locate leaks.

Retighten flange bolts or replace sealing gaskets.

Ensure the suction inlet is submerged to the required depth to prevent air entry.

2. Pump Casing Not Filled or Improperly Primed

If the pump casing and suction line are not fully filled with liquid before startup, the impeller will rotate in air (“dry running”), making it impossible to generate suction.

Solutions:

Before startup, fill the pump casing and suction line completely using a priming device or vacuum priming system.

Check whether the foot valve is properly sealed to prevent backflow and air entry.

After filling, release any trapped air through the vent valve.

3. Incorrect Rotation Direction

If the rotation direction of the horizontal split case pump is opposite to the design requirement, the impeller will push water toward the suction side instead of the discharge side, resulting in no water output. This is especially common after installing a new motor or after motor maintenance.

Solutions:

Before startup, “jog” the motor and verify that the rotation direction matches the arrow marked on the pump casing.

If the rotation is incorrect, swap any two of the motor power leads to correct the direction.

4. Excessive Suction Lift or Undersized Suction Pipe

When the suction water level is too low or the suction pipe diameter is too small, significant resistance occurs on the suction side, leading to cavitation or failure to draw water.

Solutions:

Check that the suction water level is above the minimum required suction height.

Ensure the suction pipe diameter meets design requirements, and minimize elbows or other sources of local resistance.

Remove any obstructions inside the pipeline.

5. Impeller Blockage or Damage

If the pumped medium contains impurities such as debris, sand, or fibrous materials, these can accumulate at the impeller inlet, causing clogging or wear. Over time, this leads to reduced flow or complete loss of discharge.

Solutions:

Stop the pump, disassemble, and clean the impeller passage thoroughly.

Inspect the impeller for wear, corrosion, or cracks; replace it if necessary.

Install a strainer at the suction inlet to prevent debris from entering.

6. Discharge Valve Closed or Blocked

If the discharge valve is closed or the discharge piping is blocked, the liquid inside the pump cannot flow out, making it appear as though the pump is not discharging water.

Solutions:

Check whether the discharge valve is open.

Inspect the discharge piping for blockages or sediment buildup.

Ensure that the check valve operates smoothly without sticking.

II. Preventive and Maintenance Recommendations

Regularly inspect suction and discharge pipelines for leaks and blockages.

Strictly follow operational procedures: fill the pump, release trapped air, and verify rotation direction before startup.

Keep the suction well clean to prevent debris from entering the impeller.

Maintain detailed operation and maintenance logs, monitoring flow, pressure, and current to detect anomalies early.

Conclusion

The most common causes of a horizontal split case pump failing to discharge water include air leakage, insufficient priming, incorrect rotation, or pipe blockage. Through systematic inspection and proper maintenance, such failures can be effectively prevented. For large double-suction horizontal split case pumps, particular attention should be paid to suction system sealing and priming procedures to ensure efficient and safe operation of the equipment.

FAQ – for Split Case Pump

Learn about the key spare parts commonly used in split case pumps.

Split Case Pump Spare Parts & Qty (2 Years)
For Packing Seal Pump
Spare Parts/Qty	Pump Qty (Including Spare Pump)
Spare Parts/Qty	1	2	3	4	5	6	8	≥10
Shaft Sleeve	1	1	1	2	2	3	4	5
Bearing Collar	1	1	1	2	2	3	4	5
Impeller Collar	0	0	0	1	1	1	2	3
Packing Seal	1	2	3	4	5	6	8	10
O Ring	1	2	3	4	5	6	8	10
Shaft	0	0	0	1	1	1	2	3
Impeller	0	0	0	1	1	1	2	3
Wear Ring	1	1	1	2	2	3	4	5
Packing Ring	0	0	0	1	1	1	2	3
Packing Gland	0	0	0	1	1	1	2	3
Bearing	1	1	1	2	2	3	4	5

For Mechanical Seal Pump
Spare Parts/Qty	Pump Qty (Including Spare Pump)
Spare Parts/Qty	1	2	3	4	5	6	8	≥10
Shaft Sleeve	1	1	1	2	2	3	4	5
Bearing Collar	1	1	1	2	2	3	4	5
Impeller Collar	0	0	0	1	1	1	2	3
Mechanical Seal	1	1	1	2	2	3	4	5
O Ring	1	2	3	4	5	6	8	10
Shaft	0	0	0	1	1	1	2	3
Impeller	0	0	0	1	1	1	2	3
Wear Ring	1	1	1	2	2	3	4	5
Mechanical Gland	0	0	0	1	1	1	2	3
Bearing	1	1	1	2	2	3	4	5

Discover how to select the right split case pump materials based on fluid properties and operating conditions.

Pump Parts	For Clear Water	For Sewage	For Seawater
Casing	Cast Iron	Ductile Iron	S.S / Super Dulex
Impeller	Cast Iron	Cast Steel	S.S / Super Dulex / Tin Bronze
Shaft	Steel	Steel	S.S / Super Dulex
Shaft Sleeve	Steel	Steel	S.S / Super Dulex
Wear Ring	Cast Iron	Cast Steel	S.S / Super Dulex / Tin Bronze
Remark	Final material depends on the liquid condition or the client’s request.

Follow the essential installation steps to ensure safe and reliable operation of the split case pump.

Standardized Installation Procedure for Split Case Pump
Work Stage	No.	Main Steps	Key Operations & Notes
I. Pre-Installation Preparation	1	Site & Foundation Inspection	• Clean the installation site and ensure sufficient space for operation and lifting. • Check the concrete foundation strength, dimensions, elevation, and anchor bolt positions according to drawings. The foundation surface should be flat and free of oil.
	2	Equipment Unpacking & Inspection	• Verify that the pump, motor, and accessories match the contract specifications. • Inspect the equipment for any transportation damage and ensure all parts are complete. • Check that all accompanying documents (drawings, manuals, certificates) are complete.
	3	Tools & Material Preparation	• Prepare lifting equipment (hoist, sling), shims, level, dial indicator, wrenches, feeler gauge, lubricants, sealant, etc. • Prepare cleaning agents and cloths for cleaning mating surfaces.
II. Pump Body Installation	4	Lifting & Positioning	• Lift the pump using the lifting holes or lugs; never lift by the pump shaft or inlet/outlet pipes. • Place the pump on the foundation, insert anchor bolts into base holes, do not tighten yet.
	5	Initial Leveling & Alignment	• Place a level on the pump’s inlet/outlet flange or machined surface, adjust shims to roughly level the pump (tolerance ≤0.1 mm/m). • Use the pump shaft centerline as a reference to preliminarily align the pump.
	6	Primary Grouting	• Pour high-strength non-shrink grout into the anchor bolt holes; the grout layer should be dense and slightly below the foundation surface. • Curing: wait until the grout is fully cured (usually 3–7 days) before fine adjustment and tightening.
	7	Final Leveling & Alignment	• After grout curing, tighten anchor bolts. • Recheck pump level with a precision level. • Motor installation & alignment: lift the motor in place, use a dial indicator or laser alignment device, align the motor to ensure pump and motor shafts are coaxial (radial & axial deviation ≤0.05 mm). Tighten motor anchor bolts after alignment.
III. Piping & Accessories Installation	8	Piping Connection	• Principle: never force pipe connections using the pump flanges to avoid stress on the pump body. • Piping should be independently supported, ensure natural alignment without stress. • It is recommended to install expansion joints near the pump inlet/outlet to absorb thermal expansion/contraction and installation errors.
	9	Seals & Cooling System	• For mechanical seals, connect flushing/cooling piping, ensure smooth flow, flushing pressure 0.05–0.15 MPa higher than seal chamber. • For packing seals, install packing and adjust gland tightness (do not overtighten initially).
	10	Lubrication & Instruments	• Add specified grade and quantity of lubricant to bearing housing to oil mark midline. • Install pressure gauge, thermometer, etc.; pressure gauge should be between pump outlet and first valve.
IV. Post-Installation Checks & Test Run	11	Final Checks	• Manual rotation: rotate coupling, ensure rotor turns smoothly, no friction or binding. • Check all bolts are tightened and guards are in place. • Jog motor: confirm rotation direction matches pump casing arrow.
	12	Priming & Test Run	• Open inlet valve, fill pump with conveyed medium, completely expel air. • Close outlet valve, start motor. • Slowly open outlet valve to desired condition, check pressure, flow, vibration, noise, bearing temperature (≤80 ℃), and seal leakage. Test run ≥2 hours.

Explore proper disassembly and maintenance procedures to maximize the split case pump service life.

Standardized Disassembly & Maintenance Procedure for Split Case Pump
Work Stage	No.	Main Steps	Key Operations & Notes
I. Pre-Disassembly Preparation	1	Shutdown & Isolation	• Safety first: slowly close the outlet valve, cut off power, and apply lockout/tagout (LOTO). • Close the inlet valve, open the pump vent and drain valves, completely drain the medium. For toxic or hazardous media, perform purging and verify safe conditions.
	2	Disconnect External Connections	• Remove coupling guard and connecting bolts. • Disconnect all pipes, instrumentation lines, and cooling/seal water lines if the pump will be lifted as a whole. Seal open ends to prevent foreign object entry.
	3	Tools & Preparation	• Prepare pullers, hydraulic wrenches, copper bars, lifting equipment, and various wrenches. • Prepare parts boxes and labels to organize and mark removed bolts and small parts for easier reassembly.
II. Pump Body Disassembly	4	Remove Accessories	• Remove pressure gauges, thermometers, and other instruments. • Open bearing housing oil drain and collect used lubricant.
	5	Remove Coupling & Bearing End Covers	• Use a puller to smoothly remove the half-coupling from the pump shaft; avoid hammering. • Remove bearing end covers and gland bolts in sequence, then remove the covers.
	6	Lift Out Rotor Assembly	• Remove bearing housing bolts on both sides of the pump and horizontally lift the entire rotor assembly (shaft, impeller, bearings, sleeves) smoothly. Avoid collisions.
	7	Disassemble Split Case Pump Body	• Loosen and remove pump casing bolts in a diagonal sequence. • Lift the pump casing carefully and place on a padded or wooden platform. Protect the split case mating surface—avoid dents or scratches.
	8	Remove Internal Components	• Before disassembly, measure and record key clearances (e.g., impeller to wear ring, bearing clearance). • Use special wrenches to remove impeller locknut, then remove impeller. Remove shaft sleeve, mechanical seal or packing housing sequentially.
III. Inspection, Maintenance & Reassembly	9	Parts Cleaning, Inspection & Measurement	• Clean all parts thoroughly, inspect for wear, corrosion, cracks. Focus on: – Impeller: cavitation, wear, dynamic balance. – Wear ring/seal ring: measure wear gap; replace if exceeding limits (typically >1.5× original gap). – Pump shaft: check straightness (total runout ≤0.05 mm). – Bearings: check clearance, rolling surface for pitting or spalling. – Mechanical seals: check stationary/rotating faces and spring elasticity. • Decide whether to repair or replace parts.
	10	Reassembly (Reverse Order of Disassembly)	• Core principle: clean, align, and tighten evenly. • Replace all seals (O-rings, gaskets). Apply a thin layer of sealant (e.g., anaerobic) on split case mating surfaces. • Lift pump casing, tighten bolts diagonally in stages to manufacturer torque. • Reinstall rotor assembly, adjust impeller axial clearance to manufacturer spec. • Install bearings and adjust bearing clearance. • Reinstall coupling and perform precise pump-to-motor alignment (same as installation standard).
	11	Final Verification	• Manually rotate to ensure smooth, unrestricted motion. • Connect piping, add new lubricant to specified level. • Conduct final verification according to installation procedure “Priming & Test Run” to ensure normal operation parameters.

Find practical solutions to the most common split case pump operating issues.

Split Case Pump Common Faults and Solutions
Problem	Causes	Solutions
1. Pump not priming / Cannot discharge liquid	1. Suction pipe, suction valve, foot valve not primed; air ingress. 2. Pump casing or suction pipe contains trapped air. 3. Motor rotation reversed. 4. Suction inlet leakage or failure. 5. Suction lift exceeds allowable maximum.	1. Prime suction line and foot valve; eliminate air leaks. 2. Vent casing & suction line. 3. Correct motor wiring/rotation. 4. Repair suction inlet. 5. Reduce suction lift or add booster.
2. Flow insufficient / Small discharge	1. Inlet valve closed or partially closed; suction screen blocked. 2. Impeller blockage, foreign objects. 3. Wear at suction port (seal ring), impeller or casing wear. 4. Suction line contains air. 5. Pump speed too low.	1. Fully open inlet valve; clean filter/screen. 2. Remove blockage/clean impeller. 3. Repair/replace worn components. 4. Purge air from suction. 5. Restore correct operating speed.
3. Low head / Insufficient pressure	1. Impeller clearance too large or impeller damage. 2. Low rotation speed. 3. Cavitation. 4. Suction pipe diameter too small. 5. Discharge head exceeds pump capacity.	1. Adjust or replace impeller. 2. Increase speed within rating. 3. Improve suction conditions or reduce NPSH. 4. Increase suction pipe size. 5. Reduce discharge head.
4. Excessive vibration / Abnormal noise	1. Shaft misalignment. 2. Bearing damage. 3. Loose motor mounting. 4. Coupling or impeller imbalance. 5. Motor vibration. 6. Base/frame loose. 7. Improper pipe support causing resonance.	1. Re‑align pump & motor. 2. Replace bearings. 3. Secure motor base. 4. Correct balance; inspect coupling. 5. Reduce motor vibration. 6. Tighten base. 7. Add pipe supports.
5. Bearing overheating	1. Improper lubrication (insufficient, wrong type, contaminated). 2. Bearing damage. 3. Poor alignment. 4. Bearing housing misfit. 5. Insufficient cooling. 6. Excessive rotational speed.	1. Re‑lubricate with correct grease/oil. 2. Replace bearings. 3. Realign pump & motor. 4. Adjust housing fit. 5. Improve ventilation/cooling. 6. Operate within speed rating.
6. Mechanical seal leakage	• Seal faces worn, uneven, O‑ring aging, spring failure. • Packing not lubricated or tightened.	• Replace mechanical seal and O‑rings; inspect shaft finish. • Adjust packing gland; ensure correct packing and tension.
7. Motor overload / Tripped protection	1. Insufficient power supply. 2. Phase loss / Power imbalance / Poor wiring. 3. Excessive load (impeller blockage), pump stalled. 4. Excessive starting current. 5. Motor overheating. 6. Short‑circuit or earth fault.	1. Restore proper supply voltage. 2. Check wiring and phases; correct imbalance. 3. Remove blockage; clear shaft rotation. 4. Use soft start or reduced voltage starter. 5. Improve cooling. 6. Find & repair electrical fault.
8. Cannot start or slow start	1. Power supply abnormal (voltage drop). 2. Starter contactor open. 3. Motor winding open circuit. 4. Control circuit faulty.	1. Check power and restart. 2. Check and replace contactor. 3. Repair/replacement of winding. 4. Correct control wiring.
9. Pump vibration increases at no load	1. Rotor imbalance, bent shaft. 2. Loose rotating parts. 3. Coupling looseness. 4. Pump suction/delivery line back‑pressure issue.	1. Balance rotor or repair shaft. 2. Tighten rotating assembly. 3. Tighten coupling. 4. Eliminate back‑pressure and correct piping.
10. Efficiency drop / Performance deterioration	1. Wear of impeller & casing. 2. Internal passage clogging, scale/slag. 3. Air entrainment in suction. 4. Operating point far from BEP.	1. Replace worn parts. 2. Clean flow passages; flush. 3. Eliminate suction air leaks. 4. Adjust operating conditions toward BEP.

Learn the maintenance practices that help improve split case pump reliability and reduce downtime.

Daily Maintenance and Care for Split Case Pumps
Maintenance Category	Maintenance Item	Details & Standards
I. Pre‑Operation Inspection	1. Visual & Connection Check	• Check the pump casing, motor, coupling, etc., for cracks, deformation or damage. • Check all connection fasteners (especially pump‑to‑base and base bolts) for tightness to prevent leakage or vibration. • Check piping and joint areas for looseness.
	2. Lubrication Inspection	• Oil lubrication: Check if the oil level in the oil chamber is at the center mark; whether the oil is clean. Replace promptly if oil is turbid or contains impurities. • Grease lubrication: Check if the grease is sufficient and clean. Note: Water‑based bearings use grease X; motors use grease Y — the two must not be mixed.
	3. Turn Shaft & Rotation Confirmation	• Manually rotate the coupling to check if the pump shaft rotates freely with no friction noise. • Start motor briefly to confirm the rotation direction is consistent with the direction indicated by the pump arrow.
	4. Seal & Suction Check	• Check the mechanical seal and packing seal condition. • Open pump suction valve and drain water until the casing is full, then vent air (no dry running).
II. Monitoring During Operation	1. Parameter Monitoring	• Pressure & Flow: Monitor inlet and outlet pressures and flow to ensure operation within the rated range for optimum efficiency. • Bearing Temperature: Bearing temperatures should remain between 40–60 °C, and the motor temperature should not exceed 80 °C. If overheated, check lubrication and cooling systems.
	2. Vibration & Noise	• Listen to running noise: should be smooth hum. If there are abnormal noises, impacts, etc., stop and inspect immediately. • Observe vibration condition; abnormal vibration may indicate imbalance, bent shaft, uneven wear, or cavitation.
	3. Seal & Leakage Monitoring	• Mechanical seal: Normal leakage rate should not exceed 5 drops per minute. • Packing seal: Through adjustment tighten, leakage rate should be controlled at about 10‑15 drops/min (approx. 30 ml/min) depending on packing size. Adjust to desired leakage.
	4. Instruments & Motor	• Check all instruments (pressure gauge, temperature gauge, etc.) for normal readings. • Check motor current and electrical system; no abnormal heating.
III. Periodic (Planned) Maintenance	1. Lubrication Management	• Oil lubrication: Change first after 100 operating hours, then every 500 hours. • Grease lubrication: Generally replenish or change every 3 months; follow manufacturer service schedule.
	2. Seal System Maintenance	• Packing seal: Replace packing rings as needed; ensure stuffing box is properly tightened and align packing ring gaps at 90°–120°. • Mechanical seal: Check flushing liquid pressure; it should be 0.05–0.1 MPa. Replace seal if excessive wear or leakage.
	3. Bearing & Coupling Check	• Monthly manually check coupling and shaft for smooth rotation, no abnormal noise. • Periodically check bearing housing for dirt, wear and proper lubrication.
	4. Impeller & Flow Passage Cleaning	• Every 3 months or based on water quality, check impeller for buildup, corrosion, wear; clean off sediment, debris.• Check impeller clearance; if gap is too large (e.g., >0.1 mm), replace as required.
	5. Alignment & Tightening	• Periodically check alignment between pump and motor; allowable deviation ≤0.05 mm. • Retighten base bolts and major fasteners as needed.
IV. Shutdown & Long‑Term Stop	1. Normal Shutdown	• Procedure: close outlet valve first → power off → close inlet valve and pressure gauge valves.
	2. Winter Anti‑Freeze	• When ambient temperature is ≤ 0 °C, after shutdown drain water from pump body, and ensure piping is drained to prevent freezing.
	3. Long‑Term Storage	• Drain all internal water and clean thoroughly. • Apply rust preventive oil (shaft, impeller, contact areas), reinstall and protect for storage.
V. Cleaning & Record Keeping	1. Equipment Cleaning	• Weekly wipe pump body, motor, and base surfaces; especially clean motor cooling fins. • Regularly clean around instrument panels to prevent dust accumulation.
	2. Operation Records	• Establish and maintain operation & maintenance logs including operating hours, pressures, temperature, vibration, lubrication replacement time, fault handling, etc., to facilitate equipment condition tracking and planned maintenance.
